DIN Flange Bent Axis Piston Pump
DIN flange bent axis piston pumps are designed for high-pressure hydraulic systems requiring continuous operation, long service life, and reliable performance. Hydrozer offers DIN-standard bent axis piston pump solutions for mobile hydraulics, crane systems, and OEM applications.
What Is a DIN Flange Bent Axis Piston Pump?
Bent axis piston pumps are positive displacement hydraulic pumps known for high mechanical efficiency and heavy-duty durability. The DIN flange standard ensures easy installation and compatibility with a wide range of hydraulic systems. DIN flange bent axis piston pumps are widely used in mobile hydraulics and crane applications where high pressure and stable performance are required.
DIN Flange Bent Axis Pump Technical Specifications
The following table shows the technical specifications of Hydrozer DIN flange bent axis piston pumps. These models are designed for high-pressure mobile hydraulic systems including cranes, construction machinery, and industrial equipment.
| Pump Model | Dıspl. (cc) | Max.Peak/Contınuous Pressure (bar) | Maxımum Speed (rpm) | Max. Torque Absorbed at 380 Bar (N.m) | Weight Wıthout Inlet Fıttıng (Kg) |
|---|---|---|---|---|---|
| 7APD12 | 12 | 420/380 | 3150 | 76 | 9,2 |
| 7APD18 | 18 | 420/380 | 2900 | 114 | 9,3 |
| 7APD25 | 25 | 420/380 | 2750 | 159 | 11 |
| 7APD32 | 32 | 420/380 | 2700 | 204 | 11,1 |
| 7APD41 | 41 | 420/380 | 2550 | 261 | 11,2 |
| 7APD50 | 50,3 | 420/380 | 2450 | 318 | 11,3 |
| 7APD63 | 63 | 420/380 | 2300 | 401 | 11,35 |
| 7APD80 | 80,4 | 420/380 | 2150 | 509 | 14,8 |
| 7APD108 | 108 | 420/380 | 1900 | 687 | 14,9 |
| 7APD130 | 130 | 420/380 | 1750 | 827 | 15,3 |
NOTE: Technical values vary depending on system requirements such as pressure, flow rate, and application. Our technical team supports optimal pump selection based on your project needs.
Application Areas
Crane Hydraulic Systems
Mobile Hydraulic Systems
OEM Hydraulic Projects
DIN flange bent axis piston pumps provide reliable performance and high-pressure resistance in crane hydraulic systems operating under heavy-duty conditions.
Their compact design and high efficiency make them suitable for mobile machines requiring stable power transmission.
Standardized flange compatibility and flexible configurations make these pumps ideal for OEM hydraulic system designs.
Advantages of DIN Flange Bent Axis Piston Pumps
DIN standard mounting compatibility
High efficiency with reduced heat generation
Heavy-duty design for demanding applications
Long service life and low maintenance requirements
Suitable for OEM and distributor-based projects
How to Select the Right DIN Flange Bent Axis Pump?
To select the correct pump configuration, the following information is required: operating pressure range, required flow rate, drive type (PTO, electric motor, or engine), system type (open or closed loop), and application area. Based on these parameters, our technical team recommends the most suitable DIN flange bent axis piston pump solution.
Request a Quote
Share your application details and receive a customized DIN flange bent axis piston pump recommendation and price quotation from our technical team.
← Back to all bent axis piston pump series
← View the complete product range on our hydraulic piston pumps page.
DIN Flange Bent Axis Piston Pump | High Pressure Hydraulic Pumps | Hydrozer
Frequently Asked Questions
What is a bent axis piston pump?
A bent axis piston pump is a high-pressure hydraulic pump designed to deliver efficient fluid power in mobile and industrial hydraulic systems. Its bent axis design allows high efficiency and durability under heavy load conditions.
What is the maximum pressure of Hydrozer bent axis pumps?
Hydrozer bent axis piston pumps are designed to operate up to 420 bar depending on the model and application requirements.
Where are bent axis hydraulic pumps used?
Bent axis piston pumps are widely used in cranes, construction machinery, agricultural equipment, and mobile hydraulic systems requiring high pressure and continuous operation.
What shaft options are available?
Hydrozer pumps are available with splined and keyed shaft options to match different hydraulic system configurations.
