Double Output Axial Piston Pump
Double output axial piston pumps are designed to supply hydraulic power to two independent circuits simultaneously. With compact design, high efficiency, and reliable performance, these pumps are ideal for mobile hydraulics, crane systems, and OEM hydraulic applications requiring dual hydraulic output.
What Is a Double Output Axial Piston Pump?
A double output axial piston pump, also known as a tandem piston pump, is designed to deliver hydraulic flow to two separate hydraulic circuits from a single drive source. This configuration improves system efficiency, reduces installation space, and simplifies hydraulic system design. These pumps are widely used in mobile hydraulic equipment and crane applications.
Technical Specifications
| Pump Model | Dıspl. (cc) | Max.Peak/Contınuous Pressure (bar) | Maxımum Speed (rpm) | Max. Torque Absorbed at 380 Bar (N.m) | Weight Wıthout Inlet Fıttıng (Kg) |
|---|---|---|---|---|---|
| 7APS12 | 12 | 450/400 | 3150 | 76 | 9,2 |
| 7APS18 | 18 | 450/400 | 2900 | 114 | 9,3 |
| 7APS25 | 25 | 450/400 | 2750 | 159 | 11 |
| 7APS32 | 32 | 450/400 | 2700 | 204 | 11,1 |
| 7APS41 | 41 | 450/400 | 2550 | 261 | 11,2 |
| 7APS50 | 50,3 | 450/400 | 2450 | 318 | 11,3 |
| 7APS63 | 63 | 450/400 | 2300 | 401 | 11,35 |
| 7APS80 | 80,4 | 450/400 | 2150 | 509 | 14,8 |
| 7APS108 | 108 | 450/400 | 1900 | 687 | 14,9 |
| 7APS130 | 130 | 450/400 | 1750 | 827 | 15,3 |
NOTE: Technical values vary depending on system requirements such as pressure, flow rate, and application. Our technical team supports optimal pump selection based on your project needs.
Application Areas
Crane Hydraulic Systems
Mobile Hydraulic Systems
OEM Hydraulic Projects
Double output axial piston pumps allow independent hydraulic functions such as lifting and rotation to operate efficiently within crane systems.
These pumps are ideal for mobile machines requiring two hydraulic circuits powered by a single drive source.
Compact tandem design simplifies installation and improves efficiency in OEM hydraulic system integration.
Advantages of Double Output Axial Piston Pumps
Dual hydraulic output from single drive source
Compact and space-saving design
High efficiency and reliable performance
Reduced installation complexity
Suitable for mobile and OEM applications
How to Select the Right Double Output Axial Piston Pump
Selecting the correct double output axial piston pump requires defining operating pressure, flow requirements for both circuits, drive type, and application conditions. Our technical team provides expert support to ensure optimal pump selection.
Request a Quote
Share your application details and receive a customized double output axial piston pump recommendation and quotation.
